PFMOD ™ 2W-1 (2 Way Adjustable Filter)

🇺🇸 MADE IN THE USA 🇺🇸

Harrison Labs PFMOD 2W-1 | Adjustable 2-Way Passive 2 Channel Crossover

The ultimate high-fidelity solution for bi-amplified systems. The Harrison Laboratories PFMOD 2W-1 is a professional-grade, 2 channel, passive two-way crossover designed for seamless subwoofer integration. By combining independent stereo high-pass filtering with a mono-mixed low-pass output, the 2W-1 allows you to protect your main speakers and optimize your subwoofer performance without the noise or complexity of active electronics.

Technical Specifications

• High-Pass Section (Stereo): 50 Hz, 70 Hz, 100 Hz, or 150 Hz (Selectable)

• High-Pass Slope: 12 dB per Octave

• Low-Pass Section (Mono-Mixed): 16 Selectable points (42 Hz to 200 Hz)

• Low-Pass Slope: 18 dB per Octave (High-Isolation)

• Frequency Adjustment: Internal Factory Jumpers

• Circuit Type: Pure Passive (No Power Required)

• Chassis: Compact, Low-Profile Design
